5L Steel Gas Storage Tank Air Reservoir Can 4‑Port Container High Pressure 1/4NPT

Key Words:
Steel,Gas,Storage,Tank§Air,Reservoir,Tank§4‑Port,Air,Reservoir§Air,Reservoir,Container§Air,Reservoir,Can§High,Pressure,Gas,Storage,Tank
Note:

Package List:
1 x Steel Gas Storage Tank
Features:
1、The gas storage tank is made of high‑quality 304 stainless steel, which has good heat and corrosion resistance and is durable. 2、This gas storage tank is a device specially designed to store gas and stabilize system pressure. 3、The high‑pressure gas storage tank has 4 ports, and the finely crafted threaded opening is very accuracy and welded firmly. 4、The gas storage tank adopts argon arc welding technology as a whole, with beautiful appearance, sturdy and durable. 5、The gas storage tank is mainly used for industrial production, medical equipment, automobile energy storage tank or vacuum buffer tank.
Specification:
Item Type: Steel Gas Storage TankMaterial: 304 stainless steelUses: Industrial production, medical equipment, automotive energy storage tank vacuum buffer tankCapacity: 5LWithstand Pressure: 1.25MPaMedium: AirTank Diameter: Approx. 159mm / 6.3inTank Length: Approx. 280mm / 11inHeight: Approx. 215mm / 8.5inTop Through Hole Specification: Approx. 19.5mm / 0.8inHead Through Hole Specification: Approx. 11.5mm / 0.5inBottom Through Hole Specification: Approx. 11.5mm / 0.5inInstructions For Use: 1. The working pressure of the gas storage tank shall not be higher than the maximum working pressure of 1.25MPa, the user shall be responsible for the consequences caused by overpressure use2. The gas storage tank is used in conjunction with the connecting parts (trachea joints, plugs, safety valves, pressure gauges, drain valves) and can only work after debugging.3. The use of simple pressure vessels (gas tanks) does not require registration for use, and does not require periodic inspections within the recommended service life. The gas tank after reaching the recommended service life (7-10 years) should be scrapped.4. The gas storage tank should be placed on a flat working surface to avoid cracks in the welded joint between the bracket and the simplified body during the vibration process, which may cause safety accidents.5. The shell of the gas storage tank should avoid external impact or extra heavy pressure, and avoid corrosive materials contacting the shell or working in a corrosive environment.6. The bottom drain valve of the gas storage tank should be opened regularly to drain the accumulated water to prevent corrosion inside the tank.7. After the gas storage tank is put into use, the gas storage tank shall not be excavated or repaired by welding.
Product Image:
